Full Technical Specifications
- Model
- JBC-35
- Drum geometric volume
- 5.5 m³
- Gearbox
- JBJ-320 (4 forward / 4 reverse)
- Warranty
- 2 years or 2,000 motor hours
Construction MachineryMini Concrete Mixer TrucksJFMIXJBC-35
JFMIX JBC-35 — Self-Loading Concrete Mixer (3.5 m³)
The SHANYU JBC-35 is a highly mobile self-loading concrete mixer that provides the full concrete production cycle directly on the construction site. 4x4 full drive, high passability, and an integrated loading system make it indispensable for road construction, private projects, and commercial sites.
- Concrete volume per cycle 3.5 m³
- Mixer output 14 m³/h
- Engine YUCHAI 4105 turbo-charger (115 HP)
Key Parameters
- Concrete volume per cycle
- 3.5 m³
- Mixer output
- 14 m³/h
- Engine
- YUCHAI 4105 turbo-charger (115 HP)
- Drive
- 4x4
- Operating weight
- 8,300 kg
- 01All-in-one system: The JBC-35 loads aggregates (sand, gravel, cement), mixes them, and distributes concrete where needed, eliminating the need for additional equipment.
- 02High productivity: In one cycle, the machine produces 3.5 m³ of ready concrete, and its output reaches 14 m³ per hour.
- 03High passability (4x4): 4x4 full drive and a powerful 115 HP YUCHAI engine ensure stable movement in difficult off-road conditions.
- 04Simple control: A gearbox with 4 forward and 4 reverse gears allows the operator to precisely control movement and concrete delivery.
Official Warranty
2 years or 2,000 motor hours
