Full Technical Specifications
- Model
- CF35A
- Free lift height
- 1,600 mm
- Fork dimensions
- 1,220 × 125 × 45 mm
- Warranty
- 2 years or 2,000 motor hours
Construction MachineryForklift & Pallet-Fork LoadersSHANYUCF35A
SHANYU CF35A — Diesel Forklift (3.5 tons)
Reliable, powerful, and high-performing, the SHANYU CF35A is designed to work steadily under heavy loads. Thanks to its diesel engine, this model is ideal for outdoor areas, construction sites, and warehouses where equipment must operate intensively throughout the day.
- Load capacity 3,500 kg
- Maximum lift height 4,500 mm
- Engine Xinchai C490BPG (54 HP) diesel
Key Parameters
- Load capacity
- 3,500 kg
- Maximum lift height
- 4,500 mm
- Engine
- Xinchai C490BPG (54 HP) diesel
- Number of mast stages
- 3
- Operating weight
- 4,850 kg
- 01High load capacity (3.5 tons): The CF35A safely and quickly handles loads of up to 3,500 kg, making it essential for heavy industry and logistics.
- 02Powerful XINCHAI engine: Equipped with a 54 HP diesel engine known for long service life and durability in difficult working conditions.
- 033-stage mast: The forklift is equipped with a 3-stage mast, increasing lifting flexibility and precision (maximum height 4,500 mm), while the 1,600 mm free-lift function helps the operator handle loads without obstacles.
- 04Practical dimensions: The 4,850 kg operating weight ensures strong machine stability, which is critical when placing loads at height.
Official Warranty
2 years or 2,000 motor hours
