Full Technical Specifications
- Model
- WZ30-25
- Operating weight
- 7,400 kg
- Max. digging depth
- 4,000 – 5,500 mm
- Dimensions (L/W/H)
- 5,800 × 2,268 × 3,760 mm
- Warranty
- 2 years or 2,000 motor hours
Construction MachineryBackhoe LoadersSHANYUWZ30-25
SHANYU WZ30-25
The multifunctional SHANYU WZ30-25 is designed for maximum productivity in demanding construction conditions. The combination of front loading and rear digging systems makes it an essential machine on site, saving time and reducing the need for additional equipment.
- Load capacity 2,500 kg
- Front bucket capacity 1.2 m³
- Rear bucket capacity 0.3 m³
Key Parameters
- Load capacity
- 2,500 kg
- Front bucket capacity
- 1.2 m³
- Rear bucket capacity
- 0.3 m³
- Engine
- YUCHAI 4105 Turbo-charger
- Power
- 115 HP (85 kW)
- 01Universal operation (2-in-1): The front 1.2 m³ bucket is designed for fast handling of bulk materials, while the rear 0.3 m³ excavator system provides precision and depth during digging.
- 02Powerful YUCHAI engine: Equipped with a 115 HP (85 kW) YUCHAI 4105 turbo-diesel engine, delivering high traction and durability during intensive operation.
- 03Impressive working parameters: Maximum digging depth ranges from 4,000 to 5,500 mm, enabling fast execution of deep utility and foundation works.
- 04Structural durability: The 7,400 kg operating weight provides stability and balanced performance under load.
Official Warranty
2 years or 2,000 motor hours
