BOSCH REXROTH A10VO Series Axial-Piston Pump

Bosch Rexroth A10VO is a leading variable-displacement axial-piston pump for open-circuit hydraulic systems. It is widely used in construction, agricultural, and mobile machinery due to its high efficiency and reliability.

Operating parameters depend on the specific pump series
Operating pressure
Series 31 / 32 / 60 nominal pressure is 280 bar (4,100 psi); maximum peak pressure is 350 bar (5,100 psi).

Key technical specifications

Operating parameters depend on the specific pump series
Operating pressure
Series 31 / 32 / 60: nominal pressure is 280 bar (4,100 psi); maximum peak pressure is 350 bar (5,100 psi).
Series 52 / 53: nominal pressure is 250 bar (3,600 psi); maximum peak pressure is 315 bar (4,550 psi).
Technical data matrix by size (NG)
The table shows standard nominal values (based on series 31/52) for different pump sizes

Key Parameters

Size (NG)	Displacement (cm³/rev)	Max. Speed (rpm, free suction)	Max. Flow (L/min, at max. speed)	Max. Power (kW, at Pn pressure)	Approx. Weight (kg)
NG 10	10.5	3,600	37.8	15.8	8.5
NG 18	18.0	3,300	59.4	27.7	12.0
NG 28	28.0	3,000	84.0	39.2	15.0
NG 45	45.0	2,600	117.0	54.6	21.0
NG 71	71.0	2,200	156.2	72.8	33.0
NG 100	100.0	2,000	200.0	93.3	45.0
NG140	140.0	1,800	252.0	117.6	62.0

01Main advantages
02High energy efficiency: the swashplate design precisely regulates oil flow according to demand, reducing wasted power and fuel consumption.
03Ideal power-to-weight balance: the pump has a compact design and high power density, making it easy to install in limited mounting spaces.
04Wide range of control options: supports pressure and flow control (DFR/DFR1), constant power control, and electro-proportional control (EP).
05Low noise and vibration: special pre-compression technology reduces pressure pulsation by up to 50%, ensuring quiet system operation in the operator cabin.
06Long service life: durable bearings and an optimized lubrication system withstand high radial and axial loads, minimizing maintenance costs.
07High self-priming speed: excellent suction characteristics at high speeds without the need for an additional auxiliary pump.
