INTERPUMP POWER PACK

12V-24V

Interpump Micro-Power Pack offers a unique combination of exceptional compactness and high-pressure hydraulic performance. It is engineered as a highly versatile, tubeless modular system primarily used in mobile machinery and confined industrial applications

Manufacturer / Brand Interpump Group
Maximum Working Pressure 250 bar
Pump Displacement Group 1 external gear pumps: 1 cc/rev to 9.8 cc/rev

Technical Specifications

Manufacturer / Brand: Interpump Group
Maximum Working Pressure: 250 bar
Pump Displacement: Group 1 external gear pumps: 1 cc/rev to 9.8 cc/rev
Motor Type (DC brushed): Direct Current (DC) motors: 12V and 24V versions
Motor Power: 1.6 kW to 3 kW Rated for intermittent or continuous duty cycles
Oil Reservoir Capacity: 10 L / 20 L Plastic or steel construction with mounting brackets
Valve Cavities: SAE 8 standard (¾”-16 UNF)
Connection Ports: Standard thread: Ø1/4” BSP (Options: Ø3/8”, SAE, or NPT)

01Extreme Compactness: Small physical footprint allows direct integration into tight machine spaces without complex infrastructure.
02Tubeless Modular Design: Eliminates the need for external tubes and connecting pipes during assembly, drastically reducing leak risks.
03High Pressure Capability: Delivers up to 250 bar of maximum operating pressure despite its micro size.
04Flexible Circuit Setup: Built-in manifold options easily adapt to single-effect, double-effect, or electro-distributor cartridge configurations.
05Broad Customization: Compatible with Group 1 gear pumps (1 cc/rev to 9.8 cc/rev) and customizable steel or plastic oil tanks.
06Motor Adaptability: Seamlessly mounts both Direct Current (12V to 24V DC for mobile setups) and Alternating Current (AC for factory floors) electric motors.
07Advanced Control Options: Circuit actuation can be manually operated, hydraulically piloted, or electrically driven via radio/hand controls.
