ZF Ecofluid M 75W-80 Transmission Oil

ZF Ecofluid M 75W-80 is a premium hydrocracked (synthetic technology) transmission oil specifically engineered for ZF manual and automated manual transmissions (AMT) used in commercial vehicles like trucks, buses, and light commercials. This fluid is fully approved for ZF specifications TE-ML 01E, 02E, and 16P.

SAE Viscosity Grade: 75W-80
Density at 15 °C: 0.858 g/ml (ASTM D 4052)
Kinematic Viscosity at 40 °C: 54 mm²/s (ASTM D 445)

Technical Specifications

SAE Viscosity Grade:: 75W-80
Density at 15 °C:: 0.858 g/ml (ASTM D 4052)
Kinematic Viscosity at 40 °C:: 54 mm²/s (ASTM D 445)
Kinematic Viscosity at 100 °C:: 9.3 mm²/s (ASTM D 445)
Viscosity Index:: 240 (ASTM D 2270)
Brookfield Viscosity at -40 °C:: 42 Pa.s (ASTM D 2983)
FZG Scuffing Load Stage (A/8.3/90):: > 12 (DIN 51354)

01Extended Drain Intervals, Allows for maximum oil change intervals of up to 540,000 km or 3 years (depending on operating conditions).
02Reduced Downtime: Longer service intervals mean your fleet spends less time in the workshop and more time on the road.
03Lower Operating Costs: Fewer oil changes directly translate to lower maintenance and disposal expenses over the vehicle's lifespan.
04Fuel Economy and Sustainability: Reduces fuel consumption by up to 1% compared to standard mineral transmission oils, Lower fuel consumption leads to reduced CO2 emissions, while longer oil life creates less chemical waste.
05Heavy-Load Resistance: Advanced additive technology prevents oil degradation and sludge formation under severe thermal stress.
06Shear Stability: Maintains its optimal viscosity and film strength throughout its entire service life, even under extreme mechanical pressure.
07Smooth Shifting: Provides excellent friction characteristics, ensuring easier, smoother, and quieter gear changes.
08Cold Start Performance: The high viscosity index guarantees outstanding liquidity at very low temperatures, protecting the gearbox immediately upon starting.
09Wear Reduction: Extends the life of synchronizers, bearings, and gears by offering superior anti-wear protection.
