Uniflex S4 Ecoline

UNIFLEX Hydraulic Hose Crimp Machine

UNIFLEX S4 Ecoline is a compact hydraulic hose crimping machine designed to crimp high-pressure hydraulic hoses up to 1¼ inches in diameter. It is an ideal solution for service workshops and mobile repair teams, offering reliable performance, compact dimensions, and ease of operation.

Crimping Force: 1800 kN / 180 Tons
Max. Crimping Range: 70 mm
Opening Travel: +35 mm

Technical Specifications

Crimping Force:: 1800 kN / 180 Tons
Max. Crimping Range:: 70 mm
Opening Travel:: +35 mm
Opening Without Dies:: 105 mm
Master Dies Length:: 100 mm
Control System:: Control A (Micrometer)
Motor/Drive:: 3 kW, 3-Phase VAC
Oil Capacity:: 50 Liters
Noise Level:: 69 dBA

01Greaseless Slide Bearing Technology, Zero Lubrication Required: Uses Teflon slide plates to reduce friction by 20%.
02Maximum Cleanliness: Prevents metal flaking and dirt from sticking inside the crimping head.
03Sanitary Safety: Hoses remain contamination-free, making the end product immediately suitable for food, pharmaceutical, and sanitary industries.
04High Performance-to-Size Ratio, Massive Crimp Force: Delivers a reliable 180-ton crimping force.
05Geared for Tough Materials: Offers 20% higher performance capability when crimping stronger or non-standard industrial couplings compared to competitor models.
06Deep 90° Fittings: Features long base master dies that allow smooth crimping of 90° elbow fittings up to 1 ¼ inches without snagging.
07Low Maintenance Costs: Eliminating regular manual greasing significantly reduces down-time and limits maintenance exclusively to occasional bearing plate replacement.
08Rapid Return on Investment: The Ecoline configuration provides the identical hydraulic power and robustness of premium UNIFLEX variants but optimizes control layouts to minimize upfront capital spending for small-scale workshops.
09Ergonomic and Compact Layout: The slim, narrow design fits seamlessly into mobile service vehicles or crowded workbenches without occupying excess square footage.
