Uniflex S6 Ecoline

UNIFLEX Hydraulic Hose Crimp Machine

The primary advantage of the UNIFLEX S6 Ecoline hydraulic crimper is its lubrication-free sliding bearing technology, which delivers maximum productivity with minimal maintenance costs. The "Ecoline" variant represents the brand's budget-friendly yet highly reliable workshop model.

Crimp force: 2000 kN / 200 tons
Crimp range: 6 – 100 mm
Maximum opening: +45 mm

Technical Specifications

Crimp force:: 2000 kN / 200 tons
Crimp range:: 6 – 100 mm
Maximum opening:: +45 mm
Opening without dies:: 147 mm
Oil capacity:: 50 liters
Control system:: Control A
Drive options:: 3-phase / 1-phase / 12V DC / 24V DC
Hydraulic hose:: Up to 2"
Industrial hose:: Up to 3"
2" R15 / 4SH (non-interlock fittings):: Compatible

01Grease-free technology: Teflon-coated plates eliminate the need for lubrication and reduce friction.
02Clean workspace: Without grease, metal dust and dirt do not stick to the crimping head, preventing premature wear.
03Sanitary output: Clean, grease-free operation makes the crimped hoses suitable for sanitary and food-grade applications.
04High crimping force: Delivers 200 tons (2000 kN) of crimping force, offering 20% more power than similar competitors.
05Long master dies (110 mm): Allows easy crimping of large 90-degree elbow fittings.
06Large opening: Permits crimping of up to 1½" or 2" hydraulic hoses and up to 3" industrial hoses without removing the dies.
07Compact footprint: Fits easily on any workbench or inside mobile service vans.
08Ergonomic access: A narrow and open design allows the operator to feed workpieces from either side without physical strain.
